HTTPs API

HTTPs API enables SMS submission and SMS delivery status requests. This API allows users to submit SMS messages for delivery and check the status of those deliveries. It operates over HTTPS, which ensures secure communication over the internet.

START MESSAGING TODAY!
OKRoute - HTTPs API

Authentication

Authentication information  for connecting to OKROUTE SMS platform must be requested from the owner of OKROUTE SMS platform for each new interconnection.

Credentials must be sent with each API request otherwise the user will be rejected as non-authorized.

Request Methods

Users can make requests to the API using either the GET or POST methods. GET requests are typically used for retrieving data, while POST requests are used for submitting data to be processed. The API endpoint URL is provided by the system owner and follows a specific format:

  1. http(s)://<IP_address>:<port>/api?
  2. Example URLs
  3.          https://<domainname>:8002/api?
             http://1.1.1.1:8001/api?

GET request to HTTPs port

curl -X GET  'https://<domainname>:8002/api?
        username=<username>
        &password=<password>
        &ani=<ani>
        &dnis=<dnis>
        &message=<message>
        &command=submit
        &serviceType=<serviceType>
        &longMessageMode=<longMessageMode>'
import requests

url = 'https://<domainname>:8002/api'
params = {
    'username': '<username>',
    'password': '<password>',
    'ani': '<ani>',
    'dnis': '<dnis>',
    'message': '<message>',
    'command': 'submit',
    'serviceType': '<serviceType>',
    'longMessageMode': '<longMessageMode>'
 }

response = requests.get(url, params=params)
print(response.text)
<?php
$url = 'https://<domainname>:8002/api';
$params = [
          'username' => '<username>',
          'password' => '<password>',
          'ani' => '<ani>',
          'dnis' => '<dnis>',
          'message' => '<message>',
          'command' => 'submit',
          'serviceType' => '<serviceType>',
          'longMessageMode' => '<longMessageMode>'
];

$ch = curl_init($url . '?' . http_build_query($params));
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
$response = curl_exec($ch);
curl_close($ch);

echo $response;
?>

require ‘net/http’

url = URI (“https://domainname:8002/api?username=<username>&password=<password>&ani=<ani>&dnis=<dnis>&message=<message>&command=submit&serviceType=<serviceType>&longMessageMode=<longMessageMode>“)

http = Net::HTTP.new(url.host, url.port)
http.use_ssl = true
request = Net::HTTP::Get.new(url)

response = http.request(request)
puts response.read_body

POST request to HTTP port

Credentials are part of the link

curl -X POST \
-H 'Content-Type: application/json' \
-d '{"ani":"ani","dnis":"dnis","message":"test"}' \
'http://1.1.1.1:8001/api?command=submit&username=username&password=password'

import requests

url = ‘http://1.1.1.1:8001/api?command=submit&username=username&password=password’
data = {“ani”: “ani”, “dnis”: “dnis”, “message”: “test”}
headers = {‘Content-Type’: ‘application/json’}

response = requests.post(url, json=data, headers=headers)
print (response.text)

<?php
$url = 'http://1.1.1.1:8001/api?command=submit&username=username&password=password';
$data = array("ani" => "ani", "dnis" => "dnis", "message" => "test");
$options = array(
    'http' => array(
         'header' => "Content-Type: application/json\r\n",
         'method' => 'POST',
         'content' => json_encode($data)
    )
);
$context = stream_context_create($options);
$result = file_get_contents($url, false, $context);
echo $result;
?>

require ‘net/http’
require ‘uri’
require ‘json’

uri = URI.parse(‘http://1.1.1.1:8001/api?command=submit&username=username&password=password’)
header = {‘Content-Type’: ‘application/json’}
data = {“ani” => “ani”, “dnis” => “dnis”, “message” => “test”}

http = Net::HTTP.new(uri.host, uri.port)
request = Net::HTTP::Post.new(uri.request_uri, header)
request.body = data.to_json

response = http.request(request)
puts response.body

POST request to HTTP port

Credentials are part of the JSON body

curl -H 'Content-Type: application/json' \
     -X POST \
     -d '{"username":"username","password":"password","command":"submit","ani":"ani","dnis":"dnis","message":"test"}' \
     'http://1.1.1.1:8001/api?'

import requests

url = ‘http://1.1.1.1:8001/api?’
data = {
“username”: “username”,
“password”: “password”,
“command”: “submit”,
“ani”: “ani”,
 “dnis”: “dnis”,
“message”: “test”
}
headers = {‘Content-Type’: ‘application/json’}

response = requests.post(url, json=data, headers=headers)
print (response.text)

<?php
$url = 'http://1.1.1.1:8001/api?';
$data = array(
     "username" => "username",
     "password" => "password",
     "command" => "submit",
     "ani" => "ani",
     "dnis" => "dnis",
     "message" => "test"
);
$options = array(
    'http' => array(
         'header' => "Content-Type: application/json\r\n",
         'method' => 'POST',
         'content' => json_encode($data)
    )
);
$context = stream_context_create($options);
$result = file_get_contents($url, false, $context);
echo $result;
?>

require ‘net/http’
require ‘uri’
require ‘json’

uri = URI.parse(‘http://1.1.1.1:8001/api?)
header = {‘Content-Type’: ‘application/json’}
data =  {
“username” => “username”,
“password” => “password”,
“command” => “submit”,
“ani” => “ani”,
“dnis” => “dnis”,
“message” => “test”
}

http = Net::HTTP.new(uri.host, uri.port)
request = Net::HTTP::Post.new(uri.request_uri, header)
request.body = data.to_json

response = http.request(request)
puts response.body

HTTPs API Features

SMS Submission and Delivery Status

The HTTPs API facilitates the submission of SMS messages and allows users to inquire about the delivery status of these messages. This functionality provides a comprehensive solution for managing SMS communication through the OKROUTE SMS platform.

Authentication

Securing access to the OKROUTE SMS platform, the HTTPs API mandates authentication through login/password credentials obtained from the platform owner. The inclusion of these credentials in every API request is obligatory, serving as the gateway to establishing a secure connection.

Dynamic Methods and Endpoints

Embracing unparalleled flexibility, our HTTPs API empowers you with a range of options for seamless integration. Whether it’s sending requests through the versatile GET or POST method, or ensuring security with HTTPs, our API supports your diverse needs.
